Model

SR-710

Type

Middle-range type

Laser pointer

Light source

Visible semiconductor laser (Wavelength : 660 nm)

Output

60 µW

Pulse duration

200 µs

Laser class

Class 1 Laser Product (IEC60825-1, FDA (CDRH) Part 1040.10^*1)

Lighting

Light source

High intensity red LED

Reading

Supported code

Barcode

CODE39, ITF, 2of5 (Industrial 2of5), COOP 2of5, NW-7 (Codabar), CODE128,
GS1-128, GS1 DataBar, CODE93, JAN/EAN/UPC,
Trioptic CODE39, CODE39 Full ASCII, Pharmacode

2D code

QR, MicroQR, DataMatrix (ECC200), GS1 DataMatrix, PDF417, Micro PDF417, GS1 Composite (CC-A, CC-B, CC-C)

Minimum resolution

Barcode

0.127 mm 0.005"

2D code

0.19 mm 0.008"

Reading distance (typical examples)

Barcode

45 to 195 mm 1.77" to 7.68"
(Narrow bar width = 0.5 mm 0.02")

2D code

45 to 165 mm 1.77" to 6.50"
(Cell size = 0.5 mm 0.02")

Focal distance

100 mm 3.94"

Field of view
(Typical example at focal distance)

70 mm × 45 mm 2.76" × 1.77"

I/O

Control input

2 inputs (IN1 and IN2), non-voltage input (contact, solid-state)

Control output

4 NPN open collector outputs (OUT1 to 4)
30 mA or less (24 V or less)
Residual voltage 0.8 V or less, leakage current 0.1 mA or less

RS-232C

Transmission speed

9600, 19200, 38400, 57600, 115200 bps

Supported protocol

No-protocol, MC protocol, SYSWAY, KV STUDIO

USB

USB 2.0 Full Speed compliant

Rating

Power voltage

5 VDC +5 %, -10 %

Current consumption

630 mA or less

Environmental resistance

Enclosure rating

IP65

Ambient light

Sunlight: 10,000 lux, Incandescent lamp: 6,000 lux, Fluorescent lamp: 2,000 lux

Ambient temperature

0 to +45 °C 32 to 113 °F

Storage temperature

-10 to +50 °C 14 to 122 °F (No freezing)

Relative humidity

35 to 95 % RH (No condensation)

Operating environment

No dust or corrosive gases present

Vibration resistance

10 to 55 Hz, Double amplitude 1.5 mm 0.06", 3 hours in each of the X, Y, and Z directions

Weight

Approx. 160 g (including cable)
